Vision X Reverse Light Kit 30W

Code: VXOTW0503MREV
307,13 € 253,83 € excl. VAT vision-x-usa-global-lighting-sys
In stock at supplier (1 month)
Delivery offer

Complete kit with two lights and back up light harness for easy and quick mount on cars and vans.

The VL-Series LED Light Duty offers outstanding light output in a functional design which can be easily adjusted with a single bolt bracket. High quality construction and components enable VL-Series LED Light Duty to withstand vibrations up to 21 Grms. Built-in reverse polartity protection helps prevent accidental damage caused by incorrect installation.

VL-Series Led Light Duty work lightning is a high value, versatile range designed for many light duty commercial applications.

This kit contains two work/reversing lights (TW0503M) and a full installation wiring harness with fuse and relay.

Data (one light):
Lamp housing: Composite
Lens: Polycarbonate
Mount: Rustfree steel
Beam angle: Mixed 60°/40°
Easy installation with DT plug
Voltage: 9-32 volts.
Current consumption: 1.25 Amp @ 12V
Rating: IP68 / IP69K
Approval: ADR approved
Vibration Rating: 21 Grms
Height: 72 mm
Width: 119 mm
Depth: 51 mm
Wattage: 15
Number of LED: 3 x 5W
Raw lumen: 1140
Effective lumens: 797
EMC Approval: CISPR25 Class 3
ECE approval: Yes, R23

Product Fits

2019-2024 Ram 1500 DT

Detailed information

Product detailed description

Looking for a reliable, powerful and easy to install reversing light system for your car or van? Look no further. Vision X Reverse Light Kit 30W is the answer to all your lighting needs!


Why choose Vision X Reverse Light Kit 30W?

1. Maximum performance in every situation

With this kit you get two extremely powerful LED lights (TW0503M) that offer an incredible 797 effective lumens per light! Thanks to the unique beam combination (mixed 60°/40° angle), they provide perfect illumination of the space without compromise. Whether you're reversing, working or moving in the darkest of places, these lights give you total visibility and safety.

2. Durable construction that can withstand anything

The Vision X Reverse Light Kit 30W is designed to withstand even the harshest conditions. Vibration up to 21 Grms? No problem. Thanks to high quality materials such as the composite body and polycarbonate lens, the lights will perform reliably even in the harshest environments. And what more? IP68/IP69K water and dust protection meets the highest standards - your lights will work even when submerged under water or exposed to high-pressure cleaning.

3. Easy and quick installation

Are you tired of complicated installations? You can do this with your left hand! The kit includes a complete wiring harness with fuse and relay. Thanks to the practical DT connector and the simple one-screw fixing, installation is quick and hassle-free. No more worrying about how to connect the lights - Vision X has done it for you!

4. Intelligent protection and reliability

With built-in reverse polarity protection, you don't have to worry about installation errors. The system automatically prevents damage to the lights, increasing their lifetime and reliability. In addition, this product is fully approved for road use - ADR and ECE R23 certification means it meets all the necessary safety standards.

5. Versatility for a wide range of applications

The Vision X Reverse Light Kit 30W is an ideal choice not only for passenger cars but also for light commercial applications. The 9-32V voltage makes it compatible with many types of vehicles, including vans, pick-ups and work trucks. In addition, its low power consumption (only 1.25A at 12V) saves your battery so you don't have to worry about excessive load.


Complete kit - everything you need is included!

When you get the Vision X Reverse Light Kit 30W, you get:

  • 2x LED lights TW0503M with a maximum output of 15W per light.
  • Cable harness with fuse and relay - for easy and safe installation.
  • Stainless steel mounting that is corrosion resistant and ensures a firm fixing of the lights.

Specifications:

  • Light cover: Composite material - lightweight and durable.
  • Lens: Polycarbonate - shatterproof and scratch resistant.
  • Beam angle: 60°/40° - optimum illumination of the room.
  • Voltage: 9-32V - suitable for various types of vehicles.
  • Consumption: 1.25 A at 12 V - battery friendly.
  • IP68/IP69K: Absolute protection against water and dust.
  • Dimensions: height 72 mm, width 119 mm, depth 51 mm.
  • Approvals: ECE R23, ADR, EMC (CISPR25 Class 3).

Who is this product ideal for?

The Vision X Reverse Light Kit 30W is the perfect choice for anyone looking for:

  • Maximum visibility when reversing - safer parking and driving at night.
  • Durable and reliable work lighting - for all conditions, from buildings to farms.
  • Easy and fast installation - without unnecessary complications.
  • Universal use for various types of vehicles - from passenger cars to work trucks and vans.

Get rid of the darkness once and for all!

The Vision X Reverse Light Kit 30W is not just another set of lights - it's an investment in safety, performance and reliability. Whether you're a van driver, a professional who needs reliable work lights, or a car enthusiast who wants the best lighting on the market, this kit will meet your expectations and exceed them.

Don't miss out - order the Vision X Reverse Light Kit 30W today and experience what it's like to have lights you can always rely on!


👉 Click the "Add to Cart" button and bring light where you need it most!

Additional parameters

Category: Dodge Ram 1500 5.gen DT (2019-....) Exterior
Weight: 2.1 kg
